LCR range oil holding filter bags

Item No.: SIIC-BLCR
LCR range oil holding filter bags are made from 100% polypropylene melt-blown microfiber provides great oil absorbancy. It is featured with high chemical resistance can absorb unwanted oil.
INQUIRY
Description

LCR range oil holding filter bags

Oil holding filter bag is made from 100% polypropylene melt-blown microfiber provides great oil absorbency. It is featured with high chemical resistance can absorb unwanted oil.

Features:

High flow rate, high loading capacity/Effective oil absorbancy/Multilayered construction, high surface area

Customized service available/100% polypropylene, FDA listed material

Data:

Size:1#(7"*17"),2#(7"*32")
Micron Rating (µm):1,  5,10,25,50,75,100

Recommended Operating Pressure Drop:≦1.5 kg/cm2

Max. Operating Pressure Drop:≦2 kg/cm2

Max. Operating Temperature:80℃/110℃

SIIC oil holding bag includes: SIIC-LCR-123 /SIIC-LCR-525/SIIC-AGF ranges.

SIIC-LCR-123(100 range)

1) With three filter layers

2) The efficiency is no less than 93%, some larger dust efficiency up to 99%

3) with unique fiber and deep structure, so it can block the impurities well and high oil absorbency performance

4) have a very low pressure, longer life, more economic.

5) Oil absorbency can be it’s 15-20 times of the bag weight

SIIC-LCR-525(500 range)

1) With 8-12 filter layers

2) The efficiency is no less than 95%, some larger dust efficiency up to 99%

3)  with unique fiber and multi-layer, so the filter area is bigger, then it can block the impurities well and high oil absorbency performance

4) have a very low pressure, longer life, more economic.

5) Oil absorbency can be its 15-20 times of the bag weight

SIIC-AGF filter bags

1) With 8-14 filter layers

2) The efficiency is no less than 98%, some larger dust efficiency up to 99.9%

3) With unique fiber and multi-layer, so the filter area is bigger, then it can block the impurities well and high oil absorbency performance

4) Have a very low pressure, longer life, more economic.

5) Oil absorbency can be its 15-20 times of the bag weight
