750g-800g woven fiberglass with ptfe lamination / PTFE laminated woven glass/ woven glass fiberglass with ptfe membrane/ptfe laminated woven glass in brown color which is equivalent to Donaldson’s Fiberglass cloth
1. Detailed Description Of 750g-800g woven fiberglass with ptfe lamination
Weight: 750-800g
Working Temperature: 260-300℃
Finish treatment: ptfe lamination or membrane.
Standard filter roll width: 1.1m
Roll Length: 50m or other length as per customer’s requirement
2. Features Of 750g-800g woven fiberglass with ptfe lamination
-High temperature resistant
-Made of 100% top quality fiberglass yarn
- equivalent to Donaldson’s Fiberglass cloth
3. Technical Data of 750g-800g woven fiberglass with ptfe lamination
|
750gsm woven fiberglass cloth+ptfe membrane(textured) |
|
|
Construction |
woven cloth |
|
material: ： |
textured-fiberglass |
|
Felt Area Weight |
750g/sqm(±5%) |
|
Thickness |
0.8mm±0.1 |
|
Mean Air Permeability |
2-6 m3/m2/min@12.7mmH2O |
|
Breaking Strength-MD（warp） |
>3000 N / 125px |
|
Breaking Strength-CMD（weft） |
>2000 N / 125px |
|
Breaking Elongation( N/125px)-MD（warp） |
<2.2% |
|
Breaking Elongation( N/125px)-CMD（weft） |
<1.9% |
|
Dry Shrinkage MD（240℃warp） |
＜1.5% |
|
Dry Shrinkage CMD（240℃weft） |
＜1.5% |
|
Operating Temperatures |
260 deg C |
|
Recommended Maximum Continuous |
260 deg C |
|
Recommended Maximum Surge |
300 deg C |
|
Finish |
ptfe membrane |
4. Applications Of 750g-800g woven fiberglass with ptfe lamination
As filter media, 750g-800g woven fiberglass with ptfe lamination is widely use in Industry of Steel, Chemical, Waste incineration, Cement, Construction material, Thermoelectricity.
Shanghai Filterworkshop Co., Ltd(Shanghai Indro Industry Co., Ltd) is one of China filter fabric, filter cloth, filter media manufacturers and supplies, is using high quality of filter material to make and supply China dust filter fabrics, polyester needle punched filter felt, polypropylene needle punched filter felt, acrylic PAN needle punched filter felt, nomex aramid filter felt, equivalent ryton pps filter felt, p84 filter felt, fiberglass filter cloth, ptfe felt high temperature filter felt and filter cloth with treatments of ptfe lamination, ptfe coated, water and oil repellent, anti static, silicon, graphite.
